CAPI vSphere (CAPV) - Nodes with Predefined IP Ranges

Note:

  • DKP 2.6.0+ bumps CAPV to 1.6.0+ which supports CAPI In-Cluster IPAM. An example is documented here. New implementations should use the new solution and existing implementations that are using the solution in this blog post should migrate to this by starting with an InClusterIPPool with unallocated addresses and slowly adding addresses back as they are freed up when doing upgrades.
  • If using this solution in a scenario where the CAPI resources were moved (e.g. Self Managed Cluster), the IPPool and other Custom resources that keep track of IP Allocations, don't automatically move to the cluster where the CAPI resources are being moved to. This could cause undesirable results if someone performs a cluster upgrade and the nodes being upgraded use pre-defined IPs. For this scenario, please follow the steps in the Steps for Moving to Another Cluster section of this blog.

Why Is a Predefined IP Address Range Required for Nodes When Building a Kubernetes Cluster?

When deploying Kubernetes on vSphere or another on-prem environment, it is often desirable to use an external load balancer (like F5 ) to provide a virtual ip (vip) for kubeapi server High Availability. Especially for mission critical environments where an internal load balancer (For example: Kubernetes hosted solutions like keepalived or kubevip ) may not provide the required fault tolerance or throughput. Also, these solution use ARP protocol, and thus require the VIP to be in the same subnet as the nodes, which may not always be feasible. This external load balancer-provided vip, however, must be created before provisioning the cluster as this is the endpoint used by all the nodes to join and form the cluster. This is fine when the nodes are pre-provisioned, but what about cluster creation methods like CAPV (Cluster API vSphere) where the nodes are provisioned along with the rest of the cluster creation and the IP is not known before hand? We could use a hacky solution where we create the VIP at the time of cluster creation and let the cluster creation process fail until we manually add a backend after an IP is allocated to the first control plane node. This would be extremely painful and we would have to time it perfectly for everything to go well.

That’s why a predefined IP Address range is a better solution.

The Solution

Now that we understand why we need a static IP Address range for Nodes, let’s see how to implement this for a CAPV provisioner.

The solution requires deploying two components to the CAPI cluster:

  1. metal3 ipam provider
  2. vsphere ipam adpater

The first component provides the core IPAM provider capabilities. The second component works as an adapter between CAPV (the vSphere CAPI provisioner itself), and the IPAM provider that is originally meant for metal3 CAPI provider.

Prerequisites:

  1. A working CAPI-enabled Kubernetes cluster with CAPV provider. Either deploy a KIND cluster and then manually install the CAPI components on it, or use DKP to do it by running dkp create bootstrap. More details here: https://docs.d2iq.com/dkp/latest/vsphere-bootstrap
  2. Usable Pool of IP Addresses

The following images are used:

For an airgapped setup using a KIND bootstrap cluster, follow these steps to upload the images to it:

  • Firstly, download the images to a machine that has internet connectivity using docker cli (e.g. docker pull quay.io/metal3-io/ip-address-manager:main)
  • Save the images as tar files using docker cli (e.g. docker save quay.io/metal3-io/ip-address-manager:main > ip-address-manager.tar)
  • Now upload the tars to the airgapped server hosting the bootstrap cluster and use docker load to load the images into the local docker instance (e.g. docker load -i ip-address-manager.tar )
  • Finally load the images to the KIND cluster using KIND cli (download from cli from https://github.com/kubernetes-sigs/kind/releases) (e.g. kind load docker-image quay.io/metal3-io/ip-address-manager:main --name=konvoy-capi-bootstrapper. Where, konvoy-capi-bootstrapper is the name of the kind cluster created by DKP bootstrap. If using a different mechanism of deploying the kind cluster then get the name of the cluster using kind get clusters and use in the above command as the cluster name).

Steps to Deploy CAPV With IPAM

Step 1: Clone the Vsphere-Ipam Git Repository

1
git clone https://github.com/arbhoj/vsphere-ipam.git

Step 2: Deploy Metal3 Ipam Components to the CAPI Cluster

1
kubectl create -f metal3ipam/provider-components/infrastructure-components.yaml

This will create CRD’s like ippool, ipaddresses and ipclaims along with the ipam-controller-manager deployment for the controller. It uses the quay.io/metal3-io/ip-address-manager:main image. Download, retag and push the images to a local registry and change the deployment spec to point to a local image registry for airgapped environments

Step 3: Deploy the Vsphere Ipam Adapter

1
kubectl create -f spectro-ipam-adapter/install.yaml

This will create the ipam adapter deployment for capv in the capv-system namespace with the required RBAC. It uses arvindbhoj/capv-static-ip:1.0.0 and gcr.io/kubebuilder/kube-rbac-proxy:v0.5.0 images. Download, retag and push the images to a local registry and change the deployment spec to point to a local image registry for airgapped environments

Step 4: Define the IP Address Range for the Cluster Being Provisioned

Note: The following is using examples to make it easier to explain what sample values would look like. Modify these as required.

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
export CLUSTER_NAME=dkp-demo
export NETWORK_NAME=Public #This is the name of the network to be used in vSphere
export START_IP=15.235.38.172
export END_IP=15.235.38.176
export CIDR=27
export GATEWAY=15.235.38.190
export DNS_SERVER=8.8.8.8,8.8.4.4

kubectl apply -f - <<EOF
apiVersion: ipam.metal3.io/v1alpha1
kind: IPPool
metadata:
  name: ${CLUSTER_NAME}-pool
  labels:
    cluster.x-k8s.io/network-name: ${NETWORK_NAME}
spec:
  clusterName: ${CLUSTER_NAME}
  namePrefix: ${CLUSTER_NAME}-prov
  pools:
    - start: ${START_IP}
      end: ${END_IP}
      prefix: ${CIDR}
      gateway: ${GATEWAY}
  prefix: 27
  gateway: ${GATEWAY}
  dnsServers: [${DNS_SERVER}]
EOF

Change the IP Pool name, network-name label and ip address pool, gateway and dnsServer details as required.

Step 5: Generate the Manifests for Deploying a VSphere Cluster via Cluster Api.

This would be something like this for a DKP cluster.

Note: The following example is deploying kube-vip to manage the control plane vip and binding it to eth0 interface. If control plane VIP is being managed by an external LB/Proxy, open the generated manifest and delete the kube-vip deployment spec from under the files section of kubeadmcontrolplane.

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
export CLUSTER_NAME=dkp-demo
export NETWORK=Public
export CONTROL_PLANE_ENDPOINT=xxx.xxx.xxx.xxx
export DATACENTER=dc1
export DATASTORE=datastore_name
export VM_FOLDER=folder_path
export VCENTER=vcenter_host
export SSH_PUB_KEY=path_to_ssh_public_key
export RESOURCE_POOL=vcenter_resource_pool_name
export VCENTER_TEMPLATE=capi_compatible_os_template
dkp create cluster vsphere --cluster-name=${CLUSTER_NAME} --network=${NETWORK} --control-plane-endpoint-host=${CONTROL_PLANE_ENDPOINT} --data-center=${DATACENTER} --data-store=${DATASTORE} --folder=${VM_FOLDER} --server=${VCENTER} --ssh-public-key-file=${SSH_PUB_KEY} --resource-pool=${RESOURCE_POOL} --vm-template=${VCENTER_TEMPLATE} --virtual-ip-interface=eth0 --dry-run -o yaml > dkp-cluster.yaml

Step 6: Update VsphereMachineTemplate to Use IPAM Insted of DHCP

The generated cluster deployment manifest will have two VsphereMachineTemplate resource definitions that define:

  • One pool of machines for Control Plane; and
  • One pool of machines for Worker Nodes. (Note: This is the default but additional worker node pools can be added to a cluster)

The IPAM solution is very flexibile and does not require all pools in a cluster to get it’s IPs from the IPAM. This is an important feature as in many cases (like the one defined earlier in this blog), only Control Plane Nodes need to have a predefined list of IPs.

So, in this step, update the VsphereMachineTemplate resource for the nodes pool(s) that is/are to get IPs from IPAM as shown below:

  1. Add the cluster.x-k8s.io/ip-pool-name: ${CLUSTER_NAME} label. This binds the MachineTemplate to the pool that was created earlier.
  2. Disable dhcp4 and dhcp6 (DHCP is default so that needs to be disabled for pool(s) using IPAM)
 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
apiVersion: infrastructure.cluster.x-k8s.io/v1beta1
kind: VSphereMachineTemplate
metadata:
  name: dkp-cluster-control-plane
  namespace: default
  labels:
    cluster.x-k8s.io/ip-pool-name: ${CLUSTER_NAME}-pool
spec:
  template:
    spec:
      cloneMode: fullClone
      datacenter: dc1
      datastore: ${DATASTORE}
      diskGiB: 80
      folder: ${VM_FOLDER}
      memoryMiB: 16384
      network:
        devices:
        - dhcp4: false
          dhcp6: false
          networkName: ${NETWORK}
      numCPUs: 4
      resourcePool: ${RESOURCE_POOL}
      server: ${VCENTER}
      template: ${capi_compatible_os_template}

Step 7: Deploy the Cluster by Deploying the Resources Defined in the Manifest to the CAPI Cluster

e.g.

1
kubectl create -f dkp-cluster.yaml

Step 8: Watch the Cluster as It Is Being Deployed

Now, observe the cluster as it is being deployed. This can be done easily using the DKP cli as shown below:

1
dkp describe cluster -c ${CLUSTER_NAME}

The above command will return something like. This indicates that it is waiting for Static IP Allocation from an IPAM instead of getting it from DHCP (default behavior):

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
NAME                                                         READY  SEVERITY  REASON                           SINCE  MESSAGE
Cluster/dkp-demo                                             False  Warning   ScalingUp                        3s     Scaling up control plane to 3 replicas (actual 1)
├─ClusterInfrastructure - VSphereCluster/dkp-demo            True                                              14s
├─ControlPlane - KubeadmControlPlane/dkp-demo-control-plane  False  Warning   ScalingUp                        3s     Scaling up control plane to 3 replicas (actual 1)
│ └─Machine/dkp-demo-control-plane-vhrlx                     False  Info      WaitingForStaticIPAllocation     10s    1 of 2 completed
└─Workers
  └─MachineDeployment/dkp-demo-md-0                          False  Warning   WaitingForAvailableMachines      16s    Minimum availability requires 4 replicas, current 0 available
    ├─Machine/dkp-demo-md-0-747c5848b4-hpzjn                 False  Info      WaitingForControlPlaneAvailable  13s    0 of 2 completed
    ├─Machine/dkp-demo-md-0-747c5848b4-kcgqb                 False  Info      WaitingForControlPlaneAvailable  13s    0 of 2 completed
    ├─Machine/dkp-demo-md-0-747c5848b4-mjjtc                 False  Info      WaitingForControlPlaneAvailable  13s    0 of 2 completed
    └─Machine/dkp-demo-md-0-747c5848b4-z4nn2                 False  Info      WaitingForControlPlaneAvailable  13s    0 of 2 completed

Note: The REASON field will continue to display WaitingForStaticIPAllocation till the machine is cloned; powered up; and an ip is allocated to it.

Run the following command to ensure that an ip got allocated to the machine

1
kubectl get $(kubectl get vspheremachines -o name | grep control) -o yaml | grep -A 3 " devices:"

The output will be something like this:

1
2
3
4
    devices:
    - gateway4: 15.235.38.190
      ipAddrs:
      - 15.235.38.172/27

If not, then for troubleshooting view the logs of the capv-static-ip-controller-manager pod and apply fixes based on that.

1
kubectl logs -f -n capv-system deploy/capv-static-ip-controller-manager  manager

Assuming everything went well, wait for some more time and run the dkp describe cluster command again.The output will look something like this:

The time this process takes, depends significantly on the time it takes to clone a template into a running VM.

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
$ dkp describe cluster -c ${CLUSTER_NAME}
NAME                                                         READY  SEVERITY  REASON                       SINCE  MESSAGE
Cluster/dkp-demo                                             False  Warning   ScalingUp                    25m    Scaling up control plane to 3 replicas (actual 1)
├─ClusterInfrastructure - VSphereCluster/dkp-demo            True                                          25m
├─ControlPlane - KubeadmControlPlane/dkp-demo-control-plane  False  Warning   ScalingUp                    25m    Scaling up control plane to 3 replicas (actual 1)
│ └─Machine/dkp-demo-control-plane-vhrlx                     True                                          4m15s
└─Workers
  └─MachineDeployment/dkp-demo-md-0                          False  Warning   WaitingForAvailableMachines  25m    Minimum availability requires 4 replicas, current 0 available
    ├─Machine/dkp-demo-md-0-747c5848b4-hpzjn                 False  Info      Cloning                      47s    1 of 2 completed
    ├─Machine/dkp-demo-md-0-747c5848b4-kcgqb                 False  Info      Cloning                      47s    1 of 2 completed
    ├─Machine/dkp-demo-md-0-747c5848b4-mjjtc                 False  Info      Cloning                      47s    1 of 2 completed
    └─Machine/dkp-demo-md-0-747c5848b4-z4nn2                 False  Info      Cloning                      47s    1 of 2 completed

Finally, all the machines will have their READY status set to True and we now have a vSphere cluster with the IPs from the range specified in the IPPOOL resource instead of randomly picking an IP from DHCP.

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
dkp describe cluster -c dkp-demo
NAME                                                         READY  SEVERITY  REASON                       SINCE  MESSAGE
Cluster/dkp-demo                                             True                                          51m
├─ClusterInfrastructure - VSphereCluster/dkp-demo            True                                          52m
├─ControlPlane - KubeadmControlPlane/dkp-demo-control-plane  True                                          51m
│ └─Machine/dkp-demo-control-plane-vhrlx                     True                                          30m                                             │ └─Machine/dkp-demo-control-plane-m9dtd                     True                                          25m
│ └─Machine/dkp-demo-control-plane-txncn                     True                                          20m
└─Workers
  └─MachineDeployment/dkp-demo-md-0                          True                                          52m
    ├─Machine/dkp-demo-md-0-747c5848b4-hpzjn                 True                                          4m7s
    ├─Machine/dkp-demo-md-0-747c5848b4-kcgqb                 True                                          4m5s
    ├─Machine/dkp-demo-md-0-747c5848b4-mjjtc                 True                                          4m28s
    └─Machine/dkp-demo-md-0-747c5848b4-z4nn2                 True                                          8m28s

Now use the dkp cli to get the kubeconfig of the newly provisioned cluster and verify that the cluster is up

1
2
3
dkp get kubeconfig -c ${CLUSTER_NAME} > ${CLUSTER_NAME}.conf
export KUBECONFIG=$(pwd)/${CLUSTER_NAME}.conf #Point kubectl to the downloaded kubeconfig
kubectl get nodes -o wide #Print the list of nodes along with their IPs

Steps for Moving to Another Cluster

ClusterAPI is designed to work in a “Management Cluster > Workload Cluster” topology, which works well with DKP Enterprise. The solution discussed in this blog works well for that classic scenario.

However, if using DKP Essentials with a Self Managed Cluster (or other scenarios where the CAPI resources were moved after the cluster build), the following extra steps need to be performed after moving CAPI resources, as the “IPPool.ipam.metal3.io” resource and other custom resources that keep track of allocated/unallocated IP Addresses are not moved automatically when the CAPI cluster resources are pivoted from the bootstrap cluster to the self managed workload cluster using the dkp move capi-resources command:

The important point to understand here is that the CAPI controllers only request IPs from the IPPool when provisioning a new VM (i.e. when the VSphereMachine resource is created). Which could be when you are creating, upgrading or scaling the nodes. So, after moving the CAPI resources, start with an IPPool with unused IP addresses and then slowly add them back to the pool as they are released during an upgrade or delete cycle.

Note: The following example is assuming that there were 6 IP’s (10.16.56.88-10.16.56.93) allocated/kept aside, for the Control Plane (i.e. 3 for initial deploy and 3 for upgrade, scaling, maintenance etc.). So only the first 3 were assigned to the Control Plane VMs (i.e. 10.16.56.88, 10.16.56.89, 10.16.56.90)

Step 1: After the cluster is pivoted to the self managed workload cluster, deploy the IPAM manifests as defined in this section and then create the IPPool resource with IPs that are kept aside for the cluster but not allocated to any VM when building the cluster. To keep things simple, create multiple ranges in the IPPool with a single IP in each range (this is not a hard requirement).

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
kubectl apply -f - <<EOF
apiVersion: ipam.metal3.io/v1alpha1
kind: IPPool
metadata:
  name: ${CLUSTER_NAME}-pool
  labels:
    cluster.x-k8s.io/network-name: ${NETWORK_NAME}
    cluster.x-k8s.io/cluster-name: ${CLUSTER_NAME}
spec:
  clusterName: ${CLUSTER_NAME}
  namePrefix: ${CLUSTER_NAME}-prov
  pools:
    - start: 10.16.56.91
      end: 10.16.56.91
    - start: 10.16.56.92
      end: 10.16.56.92
    - start: 10.16.56.93
      end: 10.16.56.93
  prefix: 20
  gateway: 10.16.48.1
  dnsServers: [${DNS_SERVER}]
EOF

Step 2: Perform activities like upgrade, updates (like node deletion), scaling etc., and update IPPool with any IP that was released, i.e. if any IP address is freed up as a result of this activity, add it as an individual IP to the list of IP addresses in the given pool. They will be used for the next upgrade/update activity that will require additional static IPs for the control plane.

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
e.g.:
kubectl apply -f - <<EOF
apiVersion: ipam.metal3.io/v1alpha1
kind: IPPool
metadata:
  name: ${CLUSTER_NAME}-pool
  labels:
    cluster.x-k8s.io/network-name: ${NETWORK_NAME}
    cluster.x-k8s.io/cluster-name: ${CLUSTER_NAME}
spec:
  clusterName: ${CLUSTER_NAME}
  namePrefix: ${CLUSTER_NAME}-prov
  pools:
    - start: 10.16.56.88
      end: 10.16.56.88
    - start: 10.16.56.89
      end: 10.16.56.89
    - start: 10.16.56.91
      end: 10.16.56.91
    - start: 10.16.56.92
      end: 10.16.56.92
    - start: 10.16.56.93
      end: 10.16.56.93
  prefix: 20
  gateway: 10.16.48.1
  dnsServers: [${DNS_SERVER}]
EOF

Following this process, over a period of the next upgrade or update cycles, all the IPs that were kept aside for the cluster will once again become a part of this pool.

Well. That’s it. Hope you found this useful in setting up a vSphere environment.
