Analyzing Kubernetes Controllers Performance With Pprof

pprof is a Go standard library package, which provides tooling for collecting and analyzing profiling data from Go applications. After a profile is collected from an application, it can be analyzed and visualized with the go tool pprof command. A common technique for collecting profiles from Go applications is to import the net/http/pprof package, which will register endpoints on an existing HTTP server under the /debug/pprof/ URL. It can then be used to download live profiles from a running application.

pprof can be easily integrated into your Kubernetes controllers to help gain deeper understanding of how a controller is behaving at runtime with little performance overhead.

What Is a Profile?

The Godoc for a Profile describes them as:

A Profile is a collection of stack traces showing the call sequences that led to instances of a particular event, such as allocation.

In other words, a profile is a set of stack traces collected from a running Go application with some additional metadata attached to each stack trace which provides insight into how the application is running. This additional data might include things like memory allocation information or CPU timing of function calls.

There are a set of predefined profiles which cover most profiling use cases (heap, cpu, etc); however, it is possible to write custom profiles if you have a specific use case that isn’t covered in the builtin profiles.

The predefined profiles are as follows:

1
2
3
4
5
6

goroutine    - stack traces of all current goroutines
heap         - a sampling of memory allocations of live objects
allocs       - a sampling of all past memory allocations
threadcreate - stack traces that led to the creation of new OS threads
block        - stack traces that led to blocking on synchronization primitives
mutex        - stack traces of holders of contended mutexes

Profiling Kubernetes Controllers

Now that you know a little bit about pprof and profiling, we can look at why you might need this for Kubernetes controllers. Much like any other application, Kubernetes controllers are prone to suffering from performance issues, running out of memory, etc.

If your controller is being OOMKilled, instead of just simply increasing the memory limits and moving on, you can actually understand what is using up all the memory by collecting and analyzing heap or goroutine profiles.

Another example scenario where profiling might help is if a controller is suffering from performance issues when running at scale; collecting a cpu profile can help identify functions that are using the most CPU time.

Enabling pprof via Controller-Runtime

As of controller-runtime version v0.15.0, enabling the pprof server can be accomplished by specifying the PprofBindAddress option on the controller manager. Prior to v0.15.0, it was possible to enable profiling but required manually adding each pprof endpoint to the existing metrics server via the AddMetricsExtraHandler method.

Enabling the pprof server on your controller(s) is as simple as this:

 1
 2
 3
 4
 5
 6
 7
 8
 9
10

opts := ctrl.Options{
    // additional options
    PprofBindAddress:  "127.0.0.1:8081",
}

mgr, err := ctrl.NewManager(ctrl.GetConfigOrDie(), opts)
if err != nil {
    setupLog.Error(err, "unable to start manager")
    os.Exit(1)
}

I’d recommend always enabling profiling on your Kubernetes controllers by default because you will never know when you need it to debug a performance issue until its too late. Keeping it disabled by default will prevent you from easily debugging performance issues when they pop up because enabling the pprof server will require restarting the pod.

Note: The pprof endpoints expose sensitive information so they should always be bound to 127.0.0.1 or kept private by other techniques i.e. using kube-rbac-proxy.

Collecting and Analyzing Profiles

Now that you have profiling enabled on your controllers, you can simply port-forward to the controller pod and collect profiles.

1

kubectl port-forward pod/<pod> 8081:8081

Collect a CPU profile:

1

curl -s "http://127.0.0.1:8081/debug/pprof/profile" > ./cpu-profile.out

Open the pprof web interface to analyze the profile:

1

go tool pprof -http=:8080 ./cpu-profile.out

Tip: I find flame graphs to be the one of the most valuable visualizations when analyzing most profiles, which can be done by navigating to http://localhost:8080/ui/flamegraph.
